Atlas Copco (G4-145T AP 230/1) G4 5-HP 71-Gallon AP Rotary Screw Air Compressor (230V 1-Phase 145 PSI)

SKU: 8152103803

$6,375.00

  • Specifications
  • Shipping & Returns
Atlas Copco 8152103803 (G4-145T AP 230/1) G4 5-HP 71-Gallon AP Rotary Screw Air Compressor (230V 1-Phase 145 PSI)

Latest Generation Oil-Injected Belt-Driven G Series
Ideal for small to medium businesses
100% duty cycle operates continuously in the harshest environments Quiet Performance
Allows for installation close to the point of use
A full sound enclosure reduces noise level and vibration Powerful Drivetrain w/ IE3 Premium Efficiency TEFC Motor
Lowers operation cost and motor bearing are greased for life
Designed to operate at ambient temperatures up to 115°F (46°C) Elektronikon Base Controller
Includes emergency stop, service indications and visual alerts
Easy-to-use display for pressure settings, running hours and temp. readings Spin-On Oil Separator & Oil Filter
2-step separator system reduces oil consumption
Protect production tools and the quality of your final products 71-Gallon ASME Air Receiver
1/2″ NPT air outlet integrates easily with your equipment
Manual tank drain prevents air contamination & prolongs tool life 1-Year Bumper-to-Bumper
Plug and play installation AIRkeeper app available for remote control, real-time alerts and air leakage detection

Product Category
Air Compressor – Stationary

Voltage
230 Volt AC

Phase
1-Phase

dBA
62

Amp Draw
Consult Certified Electrician

Recommended Breaker
Consult Certified Electrician

HP
5

CFM
18

CFM Rated @
145 PSI

Pump Material
Solid Cast Iron

Max PSI
145 PSI

Oil Sight Glass
Yes

Pump Type
Rotary

After Cooler
No

Pump Drive
Belt Drive

Oil Type
Oil Lubricated

Duty Cycle
100%

Tank Size
71 Gallons

Tank Included
Yes

Tank Outlet
1/2 Inch

Electronic Drain Valve
No

Tank Orientation
Horizontal

Oil Coalescing
Yes

Pressure Gauge
Yes

Air Dryer
No

Air Filter
Yes

Product Category
Air Compressor – Stationary

Weight
419 Pounds

Certification
UL/CSA, ASME

Consumer Warranty
1 Year

Commercial Warranty
1 Year

Product Depth
57 Inches

Product Width
25 Inches

Product Height
50 Inches

Power Type
Electric
