MADE IN THE USA Pulley Partner KX-2500 Red laser pulley alignment system is lightweight, compact and durable!
- Used for shots up to 6ft (1.9m) w/any size pulley
- Tool is so easy to use with single operator uses
- No training required, complete alignment service in minutes
- Extends the life of belt and pulley life
- Offers reduction of belt noise and vibration
- Displays angular, parallel, offset simultaneously
- Tested to be more accurate/efficient than other tools or conventional methods
- Laser line is projected from the transmitter to reflector mounted on the opposite pulley.
- Optional: KX-1050set Offset Bracket Kit Includes ² and ² inch adaptors
Transmitter Model KX-2500T
- Operating distance: 6 ft. (1.9 m) or better
- Accuracy: 1/16″ at 6 ft. (1.6 mm at 1.9 m)
- Laser type: 635nm visible laser diode
- Laser power: <1mW, class 2
- Laser line length: 28″ at 6 ft. (711 mm at 1.9 m)
- Controls: Laser ON/OFF rocker switch
- Operating time: 25 hours continuous at 72°F (22°C)
- Battery type: 2 AAA Alkaline Batterie
- Operating temp: 15°F (9°C) to 110°F (43°C)
- Storage temp: -4°F (-20°C) to 140°F (60°C)
- Mounting: Magnetic Weight: 10.1 oz. (286.3 g)
- Dimensions: 1.25″ (32 mm)W x 1.25″ (32 mm)D x 6.5″ (165 mm)H
- Housing: Aluminum, powder coat finish
Reflector Model KZX-2500R
- Reflector size: 1″ (25 mm) W x 1.4″ (36 mm) H
- Mounting: Magnetic
- Weight: 6.2 oz. (175.8 g)
- Dimensions: 1.25″ (32 mm)W x .75″ (19 mm)D x 6.5″ (165 mm)H
- Housing: Aluminum, powder coat finish
Carrying Case
- Material: Black, high density hard polyethylene
- Dimensions: 10.25″ (260 mm)W x 8″ (203 mm) D x 3″ (76 mm)H
- Insert: Die cut foam
- Weight of total package: 1.9 lbs. (0.9 kg)
