MADE IN THE USA Pulley Partner® Green
Pulley PRO® Green Laser Pulley Alignment System is lightweight, compact and durable!
- Used for shots up to 15 ft (4.6 m) or better
- Uses proven reflected laser beam technology
- Green laser diode technology makes our green laser line 10x’s brighter to the operator than a red laser line
- More accurate and efficient than any other tool or conventional method
- Unit magnetically attaches to inside/outside face of pulley
- Reduces vibration and belt noise and prolongs belt and pulley life
- Reduces down time and energy costs
- So easy to use, offering fast results
- Shows angular, parallel, offset simultaneously
- Tool is so easy to use with single operator uses
Transmitter Model KX-3500T
- Operating distance: 15 ft (4.6m) or better
- Accuracy: 1/16″ at 6 ft (1.6mm at 1.9m)
- Laser type: 532nm visible laser diode
- Laser power: <1mW, class 2
- Laser line length: 28″ at 6 ft (711mm at 1.9m)
- Controls: Laser ON/OFF rocker switch
- Operating time: 8 hours continuous at 72°F (22°C)
- Battery type: 2AAA lithium batteries
- Operating temp: 15°F (9°C) to 110°F (43°C)
- Storage temp: -4°F (-20°C) to 140°F (60°C)
- Mounting: Magnetic
- Weight: 10.1 oz(286.3 g)
- Dimensions: 1.25″(3mm)W x 1.25″(3mm)D x 6.5″(165mm)H
- Housing: Aluminum, powder coat finish
Reflector Model KX-3500R
- Reflector size: 1″(25mm) W x 1.4″(36mm) H
- Mounting: Magnetic Weight: 6.2 oz(175.8 g)
- Dimensions: 1.25″(32mm)W x .75″(19mm) D x 6.5″(165mm)H
- Housing: Aluminum, powder coat finish
Carrying Case
- Material: Black, high density hard polyethylene
- Dimensions: 10.25″(260mm)W x 8″(203mm)D x 3″(76mm)H
- Insert: Die cut foam
- Weight of total package: 1.9 lbs(0.9 kg)
