GAST LUBRICATED AIR MOTOR | 1AM-NCW-14

SKU: 1AM-NCW-14

$276.49

The Gast 1AM-NCW-14 Lubricated Air Motor offers adjustable speed, hub mounting, and reliable performance for industrial use. Ideal for hazardous environments, it features CE/ATEX approval and instant reversing capabilities.
  • Specifications
  • Shipping & Returns

The Gast 1AM-NCW-14 Lubricated at Kinequip is part of the compact and portable 1AM/1UP series, designed for versatile industrial use. This motor delivers adjustable speed and power output, making it ideal for applications requiring precision and flexibility.

It operates efficiently with air throttling and pressure control, offering a cost-effective alternative to electric motors. The motor can be stalled or overloaded without damage, and its cool-running, non-electrical design makes it suitable for hazardous or extreme temperature environments.

With hub mounting and a straight output shaft, the 1AM-NCW-14 can be installed in any orientation, enhancing integration into OEM systems. It features instant start, stop, and reverse capabilities, eliminating delays common with electric motors. The unit is CE and ATEX approved, rotates clockwise, and includes four vanes for reliable performance.

Quick Product Highlights

  • Lubricated air motor with hub mount
  • Max speed: 10,000 rpm
  • Max power: 0.42 hp
  • Max torque: 5.6 in-lb
  • Port size: 1/8″ NPT
  • CE and ATEX certified
  • Clockwise rotation

Get your Gast 1AM-NCW-14 Lubricated at Kinequip today.

Specifications

Max Air Consumption

20.5 cfm ( 34.83 m3h )

Max Power

0.42 hp ( 0.31 kW )

Max Pressure

7 bar ( 101.53 psi )

Max Sound Level

78 dB(A)

Max Speed

10000 rpm

Max Torque:

5.6 in-lb ( 0.63 N m )

Mount

HUB

Output Shaft Type

Straight

Port Size and Type

1/8" NPT

Regulatory Approval

CE, ATEX

Rotation

Clockwise

Stainless Steel

NO

Starting Torque @ 80psi

3.9 in-lb ( 0.44 N m )

Torque Max Speed

2.75 in-lb ( 0.31 N m )

Vanes

4

Weight

2 lbs ( 0.91 kg )
