Icotek 42241 | KEL-24-10 Split Cable Entry Frame Black
Features & Specifications:
– System enables the user to enter, seal (IP54)
– Provides strain relief for pre-terminated and standard cables
– Warranty on pre-terminated cables remains
– Easy, quick maintenance and retrofitting
– High packing density, wide variety of frames and grommets
– Strain relief according to EN 50262/EN 62444
– High stability / Vibration proof
Certifications: UL, GL, EN45545-2, ECOLAB, RoHS, IP54, NEMA12
Suitable Grommets: Suitable grommets: 10 x KT cable grommets, small
Material: Polyamide, color/black RAL9005
Material screws: Sheet steel, galvanically zinc plated
Flame class: UL94-V0, self-extinguishing
Temperature: -40 – 140 °C (static)
Properties: Halogen free, Silicone free, Anti-corrosive (V2A versions)
Mounting type: Screwing, Snap-in with KEL-SNAP
Mounting height: 17 millimeter
Material screws: Sheet steel, galvanically zinc plated
No. of screw holes: 4
Mounting height: 17 millimeter
Length: 147 millimeter
Width: 58 millimeter
Cut-out length: 112 millimeter
Cut-out width: 46 millimeter
Height: 17 millimeter
Cut-out length: 112 millimeter
Cut-out width: 46 millimeter
