The WAGO 281-623 2-Conductor Fuse Terminal Block is a compact, DIN-rail-mounted solution for protecting electrical circuits with glass cartridge fuses. It features a pivoting fuse holder that accepts standard ¼” x 1¼” fuses, allowing quick replacement without removing the terminal block from the rail.
Designed for DIN-35 rails (35 x 15 and 35 x 7.5), this terminal block supports wire sizes from 12 to 28 AWG (0.08 to 4 mm²). It uses WAGO’s CAGE CLAMP® technology for secure, tool-free connections with both solid and stranded conductors. The gray polyamide housing is flame-retardant and built to withstand industrial environments.
Rated for 800 V and 10 A, the 281-623 offers reliable performance in control panels and automation systems. It does not include blown fuse indication, making it ideal for applications where visual monitoring is not required. With a stripping length of 9–10 mm and a terminal width of 10 mm, it fits neatly into compact layouts.
Whether you’re building new systems or upgrading existing ones, this fuse terminal block provides dependable protection and easy installation.
Quick Product Highlights
- Pivoting fuse holder for ¼” x 1¼” fuses
- DIN-rail mountable (35 x 15 / 35 x 7.5)
- CAGE CLAMP® tool-free wiring
- Rated for 800 V, 10 A
- Supports 12–28 AWG conductors
Get your WAGO 281-623 2-Conductor Fuse Terminal Block at Kinequip today.
