Wago 788-307 | Relay module, Nominal input voltage: 110 VDC, 1 changeover contact, Limiting continuous cu

Relay module; Nominal input voltage: 110 VDC; 1 changeover contact; Limiting continuous current: 16 A; Red status indicator; Module width: 15 mm; 2,50 mm²; gray

Technical data:

Control Circuit:
Nominal input voltage UN DC 110 V
Input voltage range ±10 %
Nominal input current at UN 6 mA

Load circuit:
Number of changeover/switchover contacts 1
Contact material (relay) AgNi 90/10
Limiting continuous current 16 A
Inrush current (resistive) max. (AC) 30 A / 4 s
Switching voltage (max.) AC 250 V
Switching power (resistive) max. AC 4000 VA; DC (see load limit curve)
Switching capacity AC-15: 6 A / AC 250 V; DC-13: 2 A / DC 24 V
Recommended minimum load 12 V / 10 mA
Pull-in time (typ.) 8ms
Drop-out time (typ.) 6ms
Bounce time (typ.) 6ms
Electrical life (NO; resistive load; 23 °C) 30 x 10³ switching operations
Mechanical life 30 x 10⁶ switching operations
Switching frequency with/without load (max.) 6 min-1 / 1200 min-1
